Ceiling Mounted HVAC Terminal HEPA Air Filter for Clean Room


Availability:

Quantity:

Inquire Add to Basket

Model:
SB-G
Brand:
Senbao

Clean Room Ceiling Mounted HVAC Terminal HEPA Air Filter product line is the most diverse in the air filter industry.

Our ducted modules are manufactured in a range of sizes, styles and collar diameters. Faceguards, ports, and adjustable dampers are standard. Lightweight and rugged, the anodized aluminum frames allow the use of standard or HEPA Corporation's advanced "deep pleat" mini-pleat technology. Most notable with this technology is that it allows the user to efficiently reduce electrical power consumption by as much as 63%. Efficiencies range from 95% @ 0.30 microns to 99.99999+% @ 0.12 microns. Also available in HEPA-SEP aluminum separator style.

Terminal HEPA Air Filter HVAC Terminal HEPA Air Filter HEPA Air Filter HEPA Air Filter for Clean Room

Product Description

Material and performance

Frame	Aluminum
Roof material	Cold-rolled steel plate electrostatic plastic spraying, aluminum
Filter medium	Domestic Glass fiber /HV Glass fiber/Aluminum Fiol
Partition	Hot melt
Diamond of wind suiface nets	Electrolysis board electrostatic plastic spraying
Max. temperature	80°C
Max. humidity	80%RH

Specification and Technical parameters

Model	*Size LWH(mm)*	Duct Interface Size (mm)	Rate air flow(m³/h)	Intail resistance (pa)	Efficiency ( 0.3μm)
SB-G	484x484x150	250	600	≤220	≥99.99%
SB-G	610x610x150	250	1000
SB-G	915x610x150	300	1500
SB-G	1220x610x150	300	2000
special size can be according to customer special requirement
